RL78/F13, F14 CHAPTER 2 PIN FUNCTIONS
R01UH0368EJ0210 Rev.2.10 86
Dec 10, 2015
Table 2-7. Connection of Unused Pins (80-Pin Products of RL78/F13 (CAN and LIN incorporated)) (2/3)
Pin Name I/O Recommended Connection of Unused Pins
P50/(SSI01)/(INTP3) I/O Input: Independently connect to EVDD0 or EVSS0 via a resistor.
Output: Leave open.
P51/(SO01)/INTP11
P52/(SCK01)/(STOPST)
P53/(SI01)/INTP10
P54/(TI11)/(TO11)/SSI10
P55/(TI13)/(TO13)
P56/(SNZOUT1)
P57/(SNZOUT0)
P60/(SCK00)/(SCL00)
P61/(SI00)/(SDA00)/(RXD0)
P62/(SO00)/(TXD0)/SCLA0
P63/(SSI00)/SDAA0
P64/(SNZOUT3)
P65/(SNZOUT2)
P66/(TI00)/(TO00)
P67/(TI02)/(TO02)
P70/KR0/INTP8/SI11/SDA11/SNZOUT4
P71/KR1/INTP6/SCK11/SCL11/SNZOUT5
P72/KR2/(CTXD0)/SO11/SNZOUT6
P73/KR3/(CRXD0)/SSI11/SNZOUT7
P74/KR4/(SO10)/(TXD1)
P75/KR5/(SI10)/(RXD1)
P76/KR6/(SCK10)
P77/KR7/(SSI10)
P80/ANI2 Input: Independently connect to VDD or VSS via a resistor.
Output: Leave open.
P81/ANI3
P82/ANI4
P83/ANI5
P84/ANI6
P85/ANI7
P86/ANI8
P87/ANI9
P90/ANI10
P91/ANI11
P92/ANI12
P93/ANI13
P94/ANI14
P95/ANI15
P96/ANI26 Input: Independently connect to EVDD0 or EVSS0 via a resistor.
Output: Leave open.
P97/ANI27
P120/ANI25/TI07/TO07/TRDIOD0/SO01/
INTP4
Remark Functions in parentheses in the above table can be assigned via settings in the peripheral I/O redirection
registers (PIOR).
Table 2-7. Connection of Unused Pins (80-Pin Products of RL78/F13 (CAN and LIN incorporated)) (3/3)
