RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1180
Dec 10, 2015
(15) LIN/UART Mode Status Register (LMSTn)
Address: F06D1H
7 6 5 4 3 2 1 0
— — — — — — — OMM0
Value after reset:
0 0 0 0 0 0 0 0
Bit Symbol Bit Name Function R/W
0 OMM0 LIN Reset Status Monitor 0: The module is in LIN reset mode.
1: The module is not in LIN reset mode.
R
1 — Reserved This bit is always read as 0. The write value should always be 0. R
7 to 2 — Reserved These bits are always read as 0. The write value should always
be 0.
R/W
OMM0 bit (LIN reset status monitor bit)
The OMM0 bit indicates whether or not the LIN reset mode is currently set.
With 0 set, the LIN/UART module is in LIN reset mode.
With 1 set, the LIN/UART module is not in LIN reset mode.
