RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1252
Dec 10, 2015
Table 17-28. Examples of Baud Rate (19200, 10417, 9600, and 2400 bps) Generation in LIN Master Mode
LIN
communication
clock source
Prescaler
Baud rate
generator 0
N+1 frequency-
divided
Baud rate
generator 1
M+1 frequency-
divided
LIN system
clock
Baud rate Error
32 MHz 1/1 104
fa 19230.77 +0.16%
96 fd 10416.67 -0.003%
104
fb 9615.38 +0.16%
104
fc 2403.85 +0.16%
24 MHz 1/1 78
fa 19230.77 +0.16%
72 fd 10416.67 -0.003%
78
fb 9615.38 +0.16%
78
fc 2403.85 +0.16%
16 MHz 1/1 52
fa 19230.77 +0.16%
48 fd 10416.67 -0.003%
52
fb 9615.38 +0.16%
52
fc 2403.85 +0.16%
12 MHz 1/1 39
fa 19230.77 +0.16%
36 fd 10416.67 -0.003%
39
fb 9615.38 +0.16%
39
fc 2403.85 +0.16%
8 MHz 1/1 26
fa 19230.77 +0.16%
24 fd 10416.67 -0.003%
26
fb 9615.38 +0.16%
26
fc 2403.85 +0.16%
Remark The numbers in the table are for sixteen samples per bit (i.e. when NSPB[3:0] = 0000b or 1111b).
