RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 112
Dec 10, 2015
Correspondence between the address values and block numbers in the flash memory are shown below.
Table 3-1. Correspondence between Address Values and Block Numbers in Flash Memory (1/2)
Address Value
Block
Number
Address Value
Block
Number
Address Value
Block
Number
Address Value
Block
Number
00000H to 003FFH 00H 08000H to 083FFH 20H 10000H to 103FFH 40H 18000H to 183FFH 60H
00400H to 007FFH 01H 08400H to 087FFH 21H 10400H to 107FFH 41H 18400H to 187FFH 61H
00800H to 00BFFH 02H 08800H to 08BFFH 22H 10800H to 10BFFH 42H 18800H to 18BFFH 62H
00C00H to 00FFFH 03H 08C00H to 08FFFH 23H 10C00H to 10FFFH 43H 18C00H to 18FFFH 63H
01000H to 013FFH 04H 09000H to 093FFH 24H 11000H to 113FFH 44H 19000H to 193FFH 64H
01400H to 017FFH 05H 09400H to 097FFH 25H 11400H to 117FFH 45H 19400H to 197FFH 65H
01800H to 01BFFH 06H 09800H to 09BFFH 26H 11800H to 11BFFH 46H 19800H to 19BFFH 66H
01C00H to 01FFFH 07H 09C00H to 09FFFH 27H 11C00H to 11FFFH 47H 19C00H to 19FFFH 67H
02000H to 023FFH 08H 0A000H to 0A3FFH 28H 12000H to 123FFH 48H 1A000H to 1A3FFH 68H
02400H to 027FFH 09H 0A400H to 0A7FFH 29H 12400H to 127FFH 49H 1A400H to 1A7FFH 69H
02800H to 02BFFH 0AH 0A800H to 0ABFFH 2AH 12800H to 12BFFH 4AH 1A800H to 1ABFFH 6AH
02C00H to 02FFFH 0BH 0AC00H to 0AFFFH 2BH 12C00H to 12FFFH 4BH 1AC00H to 1AFFFH 6BH
03000H to 033FFH 0CH 0B000H to 0B3FFH 2CH 13000H to 133FFH 4CH 1B000H to 1B3FFH 6CH
03400H to 037FFH 0DH 0B400H to 0B7FFH 2DH 13400H to 137FFH 4DH 1B400H to 1B7FFH 6DH
03800H to 03BFFH 0EH 0B800H to 0BBFFH 2EH 13800H to 13BFFH 4EH 1B800H to 1BBFFH 6EH
03C00H to 03FFFH 0FH 0BC00H to 0BFFFH 2FH 13C00H to 13FFFH 4FH 1BC00H to 1BFFFH 6FH
04000H to 043FFH 10H 0C000H to 0C3FFH 30H 14000H to 143FFH 50H 1C000H to 1C3FFH 70H
04400H to 047FFH 11H 0C400H to 0C7FFH 31H 14400H to 147FFH 51H 1C400H to 1C7FFH 71H
04800H to 04BFFH 12H 0C800H to 0CBFFH 32H 14800H to 14BFFH 52H 1C800H to 1CBFFH 72H
04C00H to 04FFFH 13H 0CC00H to 0CFFFH 33H 14C00H to 14FFFH 53H 1CC00H to 1CFFFH 73H
05000H to 053FFH 14H 0D000H to 0D3FFH 34H 15000H to 153FFH 54H 1D000H to 1D3FFH 74H
05400H to 057FFH 15H 0D400H to 0D7FFH 35H 15400H to 157FFH 55H 1D400H to 1D7FFH 75H
05800H to 05BFFH 16H 0D800H to 0DBFFH 36H 15800H to 15BFFH 56H 1D800H to 1DBFFH 76H
05C00H to 05FFFH 17H 0DC00H to 0DFFFH 37H 15C00H to 15FFFH 57H 1DC00H to 1DFFFH 77H
06000H to 063FFH 18H 0E000H to 0E3FFH 38H 16000H to 163FFH 58H 1E000H to 1E3FFH 78H
06400H to 067FFH 19H 0E400H to 0E7FFH 39H 16400H to 167FFH 59H 1E400H to 1E7FFH 79H
06800H to 06BFFH 1AH 0E800H to 0EBFFH 3AH 16800H to 16BFFH 5AH 1E800H to 1EBFFH 7AH
06C00H to 06FFFH 1BH 0EC00H to 0EFFFH 3BH 16C00H to 16FFFH 5BH 1EC00H to 1EFFFH 7BH
07000H to 073FFH 1CH 0F000H to 0F3FFH 3CH 17000H to 173FFH 5CH 1F000H to 1F3FFH 7CH
07400H to 077FFH 1DH 0F400H to 0F7FFH 3DH 17400H to 177FFH 5DH 1F400H to 1F7FFH 7DH
07800H to 07BFFH 1EH 0F800H to 0FBFFH 3EH 17800H to 17BFFH 5EH 1F800H to 1FBFFH 7EH
07C00H to 07FFFH 1FH 0FC00H to 0FFFFH 3FH 17C00H to 17FFFH 5FH 1FC00H to 1FFFFH 7FH
To Next Page
