DTCENi2 DTC activation enable i2 R/W

0 Activation disabled R/W

1 Activation enabled

The DTCENi2 bit is set to 0 (activation disabled) by a condition for generating a transfer end interrupt.

DTCENi1 DTC activation enable i1 R/W

0 Activation disabled R/W

1 Activation enabled

The DTCENi1 bit is set to 0 (activation disabled) by a condition for generating a transfer end interrupt.

DTCENi0 DTC activation enable i0 R/W

0 Activation disabled R/W

1 Activation enabled

The DTCENi0 bit is set to 0 (activation disabled) by a condition for generating a transfer end interrupt.

Note Only in products of group E.
