RL78/F13, F14 CHAPTER 26 VOLTAGE DETECTOR

R01UH0368EJ0210 Rev.2.10 1568

Dec 10, 2015

Figure 26-4. Timing of Voltage Detector Internal Reset Signal Generation

(Option Byte LVIMDS1, LVIMDS0 = 1, 1)

Remark V

POR: POR power supply rise detection voltage

PDR: POR power supply fall detection voltage

(RESF register )

LVIRF flag

LVIF flag

LVD

VPOR = 1.56 V (TYP.)

PDR = 1.55 V (TYP.)

Supply voltage (V

)

LVIMD flag

LVILV flag

LVD reset signal

POR reset signal

Internal reset signal

Time

Cleared

Not cleared

Cleared by

software

Cleared by

software

Not cleared

Cleared
