RL78/F13, F14 CHAPTER 27 SAFETY FUNCTIONS

R01UH0368EJ0210 Rev.2.10 1584

Dec 10, 2015

(2) Flash memory CRC operation result register (PGCRCL)

This register is used to store the high-speed CRC operation results.

The PGCRCL register can be set by a 16-bit memory manipulation instruction.

Reset signal generation clears this register to 0000H.

Figure 27-2. Format of Flash Memory CRC Operation Result Register (PGCRCL)

Address: F02F2H After reset: 0000H R/W

Symbol 15 14 13 12 11 10 9 8

PGCRCL PGCRC15 PGCRC14 PGCRC13 PGCRC12 PGCRC11 PGCRC10 PGCRC9 PGCRC8

7 6 5 4 3 2 1 0

PGCRC7 PGCRC6 PGCRC5 PGCRC4 PGCRC3 PGCRC2 PGCRC1 PGCRC0

PGCRC15 to PGCRC0 High-speed CRC operation results

0000H to FFFFH Store the high-speed CRC operation results.

Caution The PGCRCL register can only be written if CRC0EN (bit 7 of the CRC0CTL register) = 1.

Figure 27-3 shows the flowchart of flash memory CRC operation function (high-speed CRC).
