RL78/F13, F14 CHAPTER 31 ON-CHIP DEBUG FUNCTION
R01UH0368EJ0210 Rev.2.10 1649
Dec 10, 2015
31.1.3 On-chip Trace
This function is for retaining the program counter values of branch sources when branches occur.
This function can retain the values of branches due to the execution of branch instructions, interrupts, and resets. This
function uses RAM to retain traces in some products.
The RAM area used and the number of branches retained by the on-chip trace vary with the product.
Table 31-1 shows the RAM area used and the number of branches retained by on-chip trace.
Table 31-1. RAM Area Used and Number of Branches Retained by On-chip Trace
Series Name Products RAM RAM Area Used
Number of
Branches
RL78/F13
(LIN incorporated)
R5F10A6A, R5F10AAA, R5F10ABA,
R5F10AGA
1 KB

64
R5F10A6C, R5F10AAC, R5F10ABC,
R5F10AGC, R5F10ALC
2 KB
R5F10A6D, R5F10AAD, R5F10ABD,
R5F10AGD, R5F10ALD
3 KB
 0FF400H-0FF42FH
(Hot plug-in/RRM and DDM by DTC)
 0FF300H-0FF37FH
(On-chip trace)
R5F10A6E, R5F10AAE, R5F10ABE,
R5F10AGE, R5F10ALE
4 KB
R5F10AME 4 KB

128
R5F10AGF, R5F10ALF, R5F10AMF 6 KB
R5F10AGG, R5F10ALG, R5F10AMG 8 KB
 0FE500H-0FE52FH
(Hot plug-in/RRM and DDM by DTC)
 0FE300H-0FE4FFH
(On-chip trace)
RL78/F13
(CAN and LIN
incorporated)
R5F10BAC, R5F10BBC, R5F10BGC,
R5F10BLC
2 KB

R5F10BAD, R5F10BBD, R5F10BGD,
R5F10BLD
3 KB
R5F10BAE, R5F10BBE, R5F10BGE,
R5F10BLE, R5F10BME
4 KB
R5F10BAF, R5F10BBF, R5F10BGF,
R5F10BLF, R5F10BMF
6 KB
R5F10BAG, R5F10BBG, R5F10BGG,
R5F10BLG, R5F10BMG
8 KB
 0FE500H-0FE52FH
(Hot plug-in/RRM and DDM by DTC)
 0FE300H-0FE4FFH
(On-chip trace)
RL78/F14 R5F10PAD, R5F10PBD, R5F10PGD 4 KB

R5F10PAE, R5F10PBE, R5F10PGE,
R5F10PLE, R5F10PME
6 KB
R5F10PPE 6 KB
R5F10PGF, R5F10PLF, R5F10PMF 8 KB
 0FE500H-0FE52FH
(Hot plug-in/RRM and DDM by DTC)
 0FE300H-0FE4FFH
(On-chip trace)
R5F10PPF 8 KB

R5F10PGG, R5F10PLG, R5F10PMG,
R5F10PPG
10 KB
R5F10PGH, R5F10PLH, R5F10PMH,
R5F10PPH
16 KB
R5F10PGJ, R5F10PLJ, R5F10PMJ,
R5F10PPJ
20 KB
 0FB500H-0FB52FH
(Hot plug-in/RRM and DDM by DTC)
 0FB300H-0FB4FFH
(On-chip trace)
