RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 147
Dec 10, 2015
Table 3-5. SFR List (1/4)
Address Special Function Register (SFR) Name Symbol R/W Manipulable Bit Range After Reset
1-bit 8-bit 16-bit
FFF00H Port register 0 P0 R/W   – 00H
FFF01H Port register 1 P1 R/W   – 00H
FFF03H Port register 3 P3 R/W   – 00H
FFF04H Port register 4 P4 R/W   – 00H
FFF05H Port register 5 P5 R/W   – 00H
FFF06H Port register 6 P6 R/W   – 00H
FFF07H Port register 7 P7 R/W   – 00H
FFF08H Port register 8 P8 R/W   – 00H
FFF09H Port register 9 P9 R/W   – 00H
FFF0AH Port register 10 P10 R/W   – 00H
FFF0CH Port register 12 P12 R/W   – Undefined
FFF0DH Port register 13 P13 R/W   – Undefined
Note
FFF0EH Port register 14 P14 R/W   – 00H
FFF0FH Port register 15 P15 R/W   – 00H
FFF10H Serial data register 00 SDR00L SDR00 R/W –   0000H
FFF11H – – –
FFF12H Serial data register 01 SDR01L SDR01 R/W –   0000H
FFF13H – – –
FFF18H Timer data register 00 TDR00 R/W – –  0000H
FFF19H
FFF1AH Timer data register 01 TDR01L TDR01 R/W –   00H
FFF1BH TDR01H –  00H
FFF1EH 10-bit A/D conversion result register ADCR R – –  0000H
FFF1FH 8-bit A/D conversion result register ADCRH R –  – 00H
FFF20H Port mode register 0 PM0 R/W   – FFH
FFF21H Port mode register 1 PM1 R/W   – FFH
FFF23H Port mode register 3 PM3 R/W   – FFH
FFF24H Port mode register 4 PM4 R/W   – FFH
FFF25H Port mode register 5 PM5 R/W   – FFH
FFF26H Port mode register 6 PM6 R/W   – FFH
FFF27H Port mode register 7 PM7 R/W   – FFH
FFF28H Port mode register 8 PM8 R/W   – FFH
FFF29H Port mode register 9 PM9 R/W   – FFH
FFF2AH Port mode register 10 PM10 R/W   – FFH
FFF2CH Port mode register 12 PM12 R/W   – FFH
FFF2EH Port mode register 14 PM14 R/W   – FFH
FFF2FH Port mode register 15 PM15 R/W   – FFH
FFF30H A/D converter mode register 0 ADM0 R/W   – 00H
FFF31H Analog input channel specification register ADS R/W   – 00H
FFF32H A/D converter mode register 1 ADM1 R/W   – 00H
FFF34H D/A conversion value setting register 0 DACS0 R/W –  – 00H
Note P130 bit depends on the setting of User Option Byte (000C2H/020C2H).
