RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 249

Dec 10, 2015

Figure 4-34. Block Diagram of P61

PORT

PU61

P61

P-ch

PU6

PM6

POM61

POM6

POM

PM61

CMOS

(Schmitt3)

PITHL6

PITHL61

PITHL

CMOS

(Schmitt1)

PMS

PMS0

(SDA00)

P61/(SI00)

(SDA00)/

(RXD0)

Internal bus

Output latch

Alternate function

Selector

P6: Port register 6

PU6: Pull-up resistor option register 6

PM6: Port mode register 6

POM6: Port output mode register 6

PMS: Port mode select register

PITHL6: Port input threshold control register 6

RD: Read signal

WRxx: Write signal
