RL78/F13, F14
CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10
291
Dec 10, 2015
Figure 4-62. Block Diagram o
f P121 and P122
Clock generator
Internal bus
P122/X2/EXCLK
RD
EXCLK, OSCSEL
CMC
OSCSEL
CMC
P121/X1
RD
CMC:
Clock operati
on m
ode control register
RD: Read
signal
322
