RL78/F13, F14
CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10
335
Dec 10, 2015
Notes 1.
Products of Groups C to E only
2.
Products of Groups C a
nd D only
3.
Group E products onl
y
4.
Products of Groups B to E only
5.
Products of Groups B to D on
ly
6.
T
he simplified IIC function (SDA
and
SCL) cannot be used
when PIOR is 1.
Cautions
1.
The 30- and 20-pin product
s do not have the PIOR4 re
gister.
2
.
Set the bit the use of which is prohibite
d to 0.
