RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 357

Dec 10, 2015

Table 4-29. Settings of Port Mode Register and Output Latch When Using Alternate Function (7/8)

Pin Name Alternate Function PIORXX POMXX PMCXX PMXX PXX PIMXX PITHLXX

Function Name I/O

P82 ANI04 Input × – – 1 × – –

IVCMP01 Input × – – 1 × – –

P83 ANI05 Input × – – 1 × – –

IVCMP02 Input × – – 1 × – –

P84 ANI06 Input × – – 1 × – –

IVCMP03 Input × – – 1 × – –

P85 ANI07 Input × – – 1 × – –

IVREF0 Input × – – 1 × – –

P86-P87 ANI08 to ANI09 Input × – – 1 × – –

P90-P95 ANI10 to ANI15 Input × – – 1 × – –

P96-P97 ANI16 to ANI17 Input × – – 1 × – –

ANI26 to ANI27

Note

Input × – 1 1 × – –

P100-

P105

ANI18 to ANI23 Input × – – 1 × – –

P106 (LTXD1) Output 1 – – 0 1 – –

P107 (LRXD1) Input 1 – – 1 × – 0/1

P120 ANI25 Input × × 1 1 × – –

TI07 Input 0 × 0 1 × – –

INTP4 Input × × 0 1 × – –

TRDIOD0 Input 0 × 0 1 × – –

Output 0 0 0 0 0 – –

SO01 Output 0 0/1 0 0 1 – –

TO07 Output 0 0 0 0 0 – –

P125 ANI24 Input × – 1 1 × × ×

TI03 Input 0 – 0 1 × 0 0/1

INTP1 Input × – 0 1 × 0 0/1

TO03 Output 0 – 0 0 0 × ×

TRDIOB0 Input 0 – 0 1 × 0 0/1

Output 0 – 0 0 0 × ×

SSI01 Input 0 – 0 1 × 0/1 0/1

SNZOUT1 Output 0 – 0 0 0 × ×

P126 (TI01) Input 1 – – 1 × – –

(TO01) Output 1 – – 0 0 – –

P127 (TI03) Input 1 – – 1 × – –

(TO03) Output 1 – – 0 0 – –

P130 RESOUT Output × – – – 0 – –

P137 INTP0 Input × – – – × – –

Note In the products of Groups B to D.

Remarks 1. : Don't care

PIORxx: Peripheral I/O redirection register

POMxx: Port output mode register

PMCxx: Port mode control register

PMxx: Port mode register

Pxx: Port output latch
