RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)

R01UH0368EJ0210 Rev.2.10 1226

Dec 10, 2015

(b) UART Buffer Transmission

The LIN/UART module (in UART mode) has a maximum of nine bytes of UART buffers, and thus it is capable of

performing continuous transmissions through the use of UART buffers.

Figure 17-25 shows the UART buffer transmission operation in the LIN/UART module (in UART mode). Table

17-19 shows the UART buffer transmission processing.

Figure 17-25. UART Buffer Transmission in LIN/UART Module (in UART mode)

ST: Start bit

P: Parity bit

SP: Stop bit

IBS: Inter-byte space

Data 0 Data 1 Data (N-1) Data N

PPP PP

IBS IBS

(1) (3)(4) (5) (6) (7) (8)(9) (10)(11)

(12)(13)(2)
