RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 307
Dec 10, 2015
4.3 Registers Controlling Port Function
Port functions are controlled by the following registers.
Port mode registers (PMxx)
Port registers (Pxx)
Pull-up resistor option registers (PUxx)
Port input mode registers (PIMxx)
Port output mode registers (POMxx)
Port mode control registers (PMCxx)
A/D port configuration register (ADPC)
Peripheral I/O redirection registers (PIORx)
Port input threshold control register (PITHLxx)
Port output slew rate select registers (PSRSEL)
SNOOZE status output control registers 0 to 3 (PSNZCNT0 to PSNZCNT3)
Port mode select register (PMS)
Table 4-26. Port Configuration of Group A Products (64-pin products) (1/4)
Port
Name
Port Bit
Output
Latch
I/O Mode
Control
Pull-up
Control
Input Type
Control
Output
Type
Control
Operating
Mode
Control
Input
Threshold
Control
PORT0 0 P0.0 PM0.0 PU0.0
1
2
3
4
5
6
7
PORT1 0 P1.0 PM1.0 PU1.0
1 P1.1 PM1.1 PU1.1
2 P1.2 PM1.2 PU1.2
3 P1.3 PM1.3 PU1.3 PIM1.3 POM1.3
PITHL1.3
4 P1.4 PM1.4 PU1.4 PIM1.4 POM1.4
PITHL1.4
5 P1.5 PM1.5 PU1.5
POM1.5
6 P1.6 PM1.6 PU1.6 PIM1.6 POM1.6
PITHL1.6
7 P1.7 PM1.7 PU1.7 PIM1.7 POM1.7
PITHL1.7
PORT2 0
1
2
3
4
5
6
7
Remark : Not provided.
