Table 4-26. Port Configuration of Group A Products (64-pin products) (2/4)
Port
Name
Port Bit
Output
Latch
I/O Mode
Control
Pull-up
Control
Input Type
Control
Output
Type
Control
Operating
Mode
Control
Input
Threshold
Control
PORT3 0 P3.0 PM3.0 PU3.0 PIM3.0   PITHL3.0
1 P3.1 PM3.1 PU3.1    
2 P3.2 PM3.2 PU3.2    
3 P3.3 PM3.3     
4 P3.4 PM3.4     
5       
6       
7       
PORT4 0 P4.0 PM4.0 PU4.0    
1 P4.1 PM4.1 PU4.1    
2 P4.2 PM4.2 PU4.2    
3 P4.3 PM4.3 PU4.3    PITHL4.3
4       
5       
6       
7       
PORT5 0 P5.0 PM5.0 PU5.0    PITHL5.0
1 P5.1 PM5.1 PU5.1    
2 P5.2 PM5.2 PU5.2    PITHL5.2
3 P5.3 PM5.3 PU5.3    PITHL5.3
4       
5       
6       
7       
PORT6 0 P6.0 PM6.0 PU6.0  POM6.0  PITHL6.0
1 P6.1 PM6.1 PU6.1  POM6.1  PITHL6.1
2 P6.2 PM6.2 PU6.2  POM6.2  
3 P6.3 PM6.3 PU6.3  POM6.3  PITHL6.3
4       
5       
6       
7       
PORT7 0 P7.0 PM7.0 PU7.0    
1 P7.1 PM7.1 PU7.1    PITHL7.1
2 P7.2 PM7.2 PU7.2    
3 P7.3 PM7.3 PU7.3    
4 P7.4 PM7.4 PU7.4    
5 P7.5 PM7.5 PU7.5    
6 P7.6 PM7.6 PU7.6    
7 P7.7 PM7.7 PU7.7    
Remark : Not provided.
