RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 361
Dec 10, 2015
4.6.2 Notes on specifying the pin settings
For an output pin to which multiple functions are assigned, the output of the unused alternate functions must be set to
its initial state so as to prevent conflicting outputs. This also applies to the functions assigned by using the peripheral I/O
redirection register (PIOR). For details about the alternate function output, see 4.5 Settings of Port Mode Register and
Output Latch When Using Alternate Function.
No specific setting is required for input pins because the output of their alternate functions is disabled (the buffer output
is Hi-Z).
Disabling the unused functions, including blocks that are only used for input or do not have I/O, is recommended for
lower power consumption.
