12.3.10 A/D test register (ADTES)

This register is used to select the + side reference voltage (AV

REFP) or - side reference voltage (AVREFM) of the A/D

converter, or the analog input channel (ANIxx) as the A/D conversion target for the A/D test function.

The ADTES register can be set by an 8-bit memory manipulation instruction.

Reset signal generation clears this register to 00H.

Figure 12-14. Format of A/D Test Register (ADTES)

Address: F0013H After reset: 00H R/W

Symbol 7 6 5 4 3 2 1 0

ADTES 0 0 0 0 0 0 ADTES1 ADTES0

ADTES1 ADTES0 A/D conversion target

0 0 ANIxx (This is specified using the analog input channel specification register (ADS).)

1 0 AVREFM

1 1 AVREFP

Other than the above Setting prohibited

Caution For details of the A/D test function, see CHAPTER 27 SAFETY FUNCTIONS.
