RL78/F13, F14 CHAPTER 12 A/D CONVERTER
R01UH0368EJ0210 Rev.2.10 720
Dec 10, 2015
12.3.5 10-bit A/D conversion result register (ADCR)
This register is a 16-bit register that stores the A/D conversion result in the select mode. The lower 6 bits are fixed to
0. Each time A/D conversion ends, the conversion result is loaded from the successive approximation register (SAR).
The higher 8 bits of the conversion result are stored in FFF1FH and the lower 2 bits are stored in the higher 2 bits of
FFF1EH
Note
.
The ADCR register can be read by a 16-bit memory manipulation instruction.
Reset signal generation clears this register to 0000H.
Note If the A/D conversion result is outside the range specified by using the A/D conversion result comparison function
(the value specified by the ADRCK bit of the ADM2 register and ADUL/ADLL registers; see Figure 12-8), the
result is not stored.
Figure 12-9. Format of 10-bit A/D Conversion Result Register (ADCR)
Cautions 1. When writing to the A/D converter mode register 0 (ADM0), analog input channel specification
register (ADS), and A/D port configuration register (ADPC), the contents of the ADCR register may
become undefined. Read the conversion result following conversion completion before writing to
the ADM0, ADS, and ADPC registers. Using timing other than the above may cause an incorrect
conversion result to be read.
2. When 8-bit resolution A/D conversion is selected (when the ADTYP bit of A/D converter mode
register 2 (ADM2) is 1) and the ADCR register is read, 0 is read from the lower two bits (ADCR1 and
ADCR0).
3. When the ADCR register is accessed in 16-bit units, the higher 10 bits of the conversion result are
read in order starting at bit 15.
Symbol
Address: FFF1FH, FFF1EH After reset: 0000H R
FFF1FH FFF1EH
000000
ADCR
