RL78/F13, F14 CHAPTER 12 A/D CONVERTER
R01UH0368EJ0210 Rev.2.10 729
Dec 10, 2015
12.3.13 A/D converter trigger select register 1 (ADTRGS1) (RL78/F13 only)
This register is used to enable or disable operation trigger generation of the A/D converter when the timer RJ0 interrupt
request is generated.
Set this register while the timer RJ0 interrupt request is not generated.
Reset signal generation clears this register to 00H.
Figure 12-17. Format of A/D Converter Trigger Select Register 1 (ADTRGS1)
Address: F078DH After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ADTRGS1 0 0 0 0 0 0 0 ADTRGS10
ADTRGS10 Selection of the operation trigger of the A/D converter when the timer RJ0 interrupt request is generated
0 The operation trigger of the A/D converter is not generated when the interrupt request is generated.
1
The operation trigger of the A/D converter is generated when the interrupt request is generated (A/D
conversion is started).
To Next Page
