21.3.5 Interrupt source determination flag register 0 (INTFLG0)
This register determines which of interrupt sources causes an interrupt, an external interrupt source (INTP4, 5, 8, 13) or
other interrupt source that are allocated to the same vector table address as the comparator detection 0 interrupt source.
The flag in this register cannot be set by software.
The flags are cleared by software.
To clear the flag, write 1 to the bits other than the bit desired to be cleared.
Use an 8-bit data transfer instruction as a write instruction.
Figure 21-6. Format of Interrupt Source Determination Flag Register 0 (INTFLG0)
ddress: F0079H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
INTFLG0
INTFLG07
Note 4, 6
INTFLG06
Notes 3, 5
0 0 0
INTFLG02
Notes 1, 2, 6
INTFLG01
Note 1, 6
INTFLG00
Note 6
INTFLG07
Note 4, 6
Interrupt source determination flag at vector table address 00014h
0 An INTP13 interrupt has not been generated.
1 An INTP13 interrupt has been generated.
INTFLG06
Notes 3, 5
Interrupt source determination flag at vector table address 00012h
0 A comparator detection 0 interrupt has not been generated.
1 A comparator detection 0 interrupt has been generated.
INTFLG02
Notes 1, 2, 6
Interrupt source determination flag at vector table address 0002Ah
0 An INTP8 interrupt has not been generated.
1 An INTP8 interrupt has been generated.
INTFLG01
Note 1, 6
Interrupt source determination flag at vector table address 00012h
0 An INTP5 interrupt has not been generated.
1 An INTP5 interrupt has been generated.
INTFLG00
,
Note 6
Interrupt source determination flag at vector table address 00010h
0 An INTP4 interrupt has not been generated.
1 An INTP4 interrupt has been generated.
Notes 1. Not provided in Group A products.
2. Not provided in the RL78/F13 (CAN and LIN incorporated) products with 30 or 32 pins and the
RL78/F14 products with 30 or 32 pins.
3. Only provided in products of Groups D and E.
4. Only provided in 80-pin products of the RL78/F14 with 128 Kbytes to 256 Kbytes of code flash
memory and 100-pin products of the RL78/F14 with 64 Kbytes to 256 Kbytes of code flash
memory.
