Renesas RL78/F14 User Manual

RL78/F13, F14 CHAPTER 21 INTERRUPT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 1498
Dec 10, 2015
Table 21-3. Ports Corresponding to EGPn and EGNn bits
Detection Enable Bit
Edge Detection
Port
Interrupt
Request Signal
80, 100-
pin
64-pin 48-pin
30, 32-
pin
20-pin
EGP0 EGN0 P137 INTP0
    
EGP1 EGN1 P125 INTP1
    
EGP2 EGN2 P30(P31) INTP2
    
EGP3 EGN3 P17 (P50) INTP3
    
EGP4 EGN4 P120 INTP4
    
EGP5 EGN5 P12 INTP5
    
EGP6 EGN6 P71 INTP6
    
EGP7 EGN7 P32 INTP7
    
EGP8 EGN8 P70 INTP8


Note 1

Note 1
 
EGP9 EGN9 P00 INTP9


Note 1

Note 1
 
EGP10 EGN10 P53 INTP10


Note 1
  
EGP11 EGN11 P51
INTP11/
INTLIN0WUP
Note
2
    
EGP12 EGN12 P77
INTP12/
INTLIN1WUP
Note
2

Note 3

Note 3
  
EGP13 EGN13 P47 INTP13 
Note 3
   
Notes 1. Not provided in Group A products.
2. Set the EGP1 and EGN1 registers before the INTLIN0WUP and INTLIN1WUP interrupts are
generated.
3. Provided only in Group E products.
Caution When the input port pins used for the external interrupt functions are switched to the output
mode, the INTPn interrupt might be generated upon detection of a valid edge. When
switching the input port pins to the output mode, set the port mode register (PMxx) to 0 after
disabling the edge detection (by setting EGPn and EGNn to 0).
Remarks 1. For edge detection ports, see 2.1 Pin Function List.
2. n = 0 to 13
