Renesas RL78/F14 User Manual

RL78/F13, F14 CHAPTER 21 INTERRUPT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 1494
Dec 10, 2015
21.3.3 Priority specification flag registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H, PR03L, PR10L, PR10H,
PR11L, PR11H, PR12L, PR12H, PR13L)
The priority specification flag registers are used to set the corresponding maskable interrupt priority level.
A priority level is set by using the PR0xy and PR1xy registers in combination (xy = 0L, 0H, 1L, 1H, 2L, 2H, or 3L).
The PR00L, PR00H, PR01L, PR01H, PR02L, PR02H, PR03L, PR10L, PR10H, PR11L, PR11H, PR12L, PR12H, and the
PR13L registers can be set by a 1-bit or 8-bit memory manipulation instruction. If the PR00L and PR00H registers, the
PR01L and PR01H registers, the PR02L and PR02H registers, the PR10L and PR10H registers, the PR11L and PR11H
registers, and the PR12L and PR12H registers are combined to form 16-bit registers PR00, PR01, PR02, PR10, PR11, and
PR12, they can be set by a 16-bit memory manipulation instruction.
Reset signal generation sets these registers to FFH.
Remark If an instruction that writes data to this register is executed, the number of instruction execution clocks
increases by 2 clocks.
Figure 21-4. Format of Priority Specification Flag Registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H,
PR03L, PR10L, PR10H, PR11L, PR11H, PR12L, PR12H, PR13L) (1/3)
A
ddress: FFFE8H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR00L PPR05
CMPPR00
PPR04
SPMPR0
PPR03 PPR02 PPR01 PPR00 LVIPR0 WDTIPR0
A
ddress: FFFECH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR10L PPR15
CMPPR10
PPR14
SPMPR1
PPR13 PPR12 PPR11 PPR10 LVIPR1 WDTIPR1
A
ddress: FFFE9H After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR00H
LIN0TRMPR
0
RAMPR0 TRJPR00 TRDPR01 TRDPR00 SRPR00
CSIPR001
IICPR001
STPR00
CSIPR000
IICPR000
CLMPR0
PPR013
A
ddress: FFFEDH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR10H
LIN0TRMPR
1
RAMPR1 TRJPR10 TRDPR11 TRDPR10 SRPR10
CSIPR101
IICPR101
STPR10
CSIPR100
IICPR100
CLMPR1
PPR113
A
ddress: FFFEAH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR01L TMPR003 TMPR002 TMPR001 TMPR000 PPR08
RTCPR0
IICAPR00
LIN0STAP
R0
LIN0PR0
LIN0RVCPR
0
