Renesas RL78/F14 User Manual

RL78/F13, F14 CHAPTER 19 DTC
R01UH0368EJ0210 Rev.2.10 1429
Dec 10, 2015
Table 19-4. DTC Register Configuration (2)
Register Name Symbol After Reset Address Access Size
High-speed DTC Channel Select Register 0 SELHS0 3FH F02E1H 1, 8
High-speed DTC Channel Select Register 1 SELHS1 3FH F02E2H 1, 8
High-speed DTC Control Register 0 HDTCCR0 00H F02D0H 1, 8
High-speed DTC Transfer Count Register 0 HDTCCT0 00H F02D2H 1, 8
High-speed DTC Transfer Count Reload
Register 0
HDTRLD0 00H F02D3H 1, 8
High-speed DTC Source Address Register 0 HDTSAR0 00H
F02D4H,
F02D5H
16
High-speed DTC Destination Address Register
0
HDTDAR0 00H
F02D6H,
F02D7H
16
High-speed DTC Control Register 1 HDTCCR1 00H F02D8H 1, 8
High-speed DTC Transfer Count Register 1 HDTCCT1 00H F02DAH 1, 8
High-speed DTC Transfer Count Reload
Register 1
HDTRLD1 00H F02DBH 1, 8
High-speed DTC Source Address Register 1 HDTSAR1 00H
F02DCH,
F02DDH
16
High-speed DTC Destination Address Register
1
HDTDAR1 00H
F02DEH,
F02DFH
16
