RL78/F13, F14 CHAPTER 21 INTERRUPT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 1483

Dec 10, 2015

Figure 21-1. Basic Configuration of Interrupt Function (3/3)

(E) External maskable interrupt (LINx wake-up)

(F) Software interrupt

IF: Interrupt request flag

IE: Interrupt enable flag

ISP0: In-service priority flag 0

ISP1: In-service priority flag 1

MK: Interrupt mask flag

PR0: Priority specification flag 0

PR1: Priority specification flag 1

Remark n = 0, 1

x = 0, 1

Note

y = 11, 12

Note

Note Except in Group E products, x = 0 and y = 11.

MK IE PR1

ISP1

PR0

ISP0

Internal bus

LRXDx pin input

Priority controller

Vector table

address generator

Standby release

signal

Edge

detector

Input switch control

External interrupt

edge enable register n

(EGPn, EGNn)

INTPy pin input

Internal bus

Interrupt

request
