RL78/F13, F14 CHAPTER 26 VOLTAGE DETECTOR
R01UH0368EJ0210 Rev.2.10 1566
Dec 10, 2015
When used as interrupt mode
Detection voltage Option byte Setting Value
VLVD LVIMDS1 LVIMDS0 VPOC2 VPOC1 VPOC0 LVIS1 LVIS0
Rising edge Falling edge
2.81 V 2.75 V 0 1 0 1 1 1 1
3.02 V 2.96 V 0 0 0 0 1
3.22 V 3.15 V 0 1 1 0 1
4.42 V 4.32 V 0 0 1 0 0
4.62 V 4.52 V 0 1 0 0 0
4.74 V 4.64 V 0 1 1 0 0
Other than above Setting prohibited
When LVDOFF
Detection voltage Option byte Setting Value
VLVD LVIMDS1 LVIMDS0 VPOC2 VPOC1 VPOC0 LVIS1 LVIS0
Rising edge Falling edge
1 1
Other than above Setting prohibited
Caution When the LVD is off, it is necessary to perform an external reset. For an external reset, input a low
level of at least 10
s or more to the RESET pin. To perform an external reset upon power application,
input a low level to the RESET pin before power-on, keep the low level for at least 10
s during the
period in which the supply voltage is within the operating range, and then input a high level. After
power is applied, do not input a high level to the RESET pin during a period in which the supply
voltage is not within the operating range.
Remark : don’t care
