RL78/F13, F14 CHAPTER 35 ELECTRICAL SPECIFICATIONS (GRADE K)

R01UH0368EJ0210 Rev.2.10 1756

Dec 10, 2015

CSI mode connection diagram (during communication at same potential)

CSI mode serial transfer timing (during communication at same potential)

(When DAPmn = 0 and CKPmn = 0, or DAPmn = 1 and CKPmn = 1)

Remark p: CSIp (p = 00, 01, 10, 11), m: Unit m (m = 0, 1), n: Channel n (n = 0, 1)

SCKp

SOp

SCK

User's device

SIp

SSIp

RL78

microcontroller

SCKp

SOp

SCK

SSO

User's device

SIp SO

SSIp

RL78

microcontroller

<Slave>
