RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 172
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (21/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After
reset
1-bit 8-bit 16-bit
F045AH CAN receive rule entry register 15BH
Note 1
GAFLMH15L GAFLMH15 R/W – √ √ 0000H
F045BH GAFLMH15H – √
F045AH CAN receive buffer register 11CH
Note 2
RMDF111L RMDF111 R – √ √ 0000H
F045BH RMDF111H – √
F045CH CAN receive rule entry register 15CL
Note 1
GAFLPL15L GAFLPL15 R/W – √ √ 0000H
F045DH GAFLPL15H – √
F045CH CAN receive buffer register 11DL
Note 2
RMDF211L RMDF211 R – √ √ 0000H
F045DH RMDF211H – √
F045EH CAN receive rule entry register 15CH
Note 1
GAFLPH15L GAFLPH15 R/W – √ √ 0000H
F045FH GAFLPH15H – √
F045EH CAN receive buffer register 11DH
Note 2
RMDF311L RMDF311 R – √ √ 0000H
F045FH RMDF311H – √
F0460H CAN receive buffer register 12AL
Note 2
RMIDL12L RMIDL12 R – √ √ 0000H
F0461H RMIDL12H – √
F0462H CAN receive buffer register 12AH
Note 2
RMIDH12L RMIDH12 R – √ √ 0000H
F0463H RMIDH12H – √
F0464H CAN receive buffer register 12BL
Note 2
RMTS12L RMTS12 R – √ √ 0000H
F0465H RMTS12H – √
F0466H CAN receive buffer register 12BH
Note 2
RMPTR12L RMPTR12 R – √ √ 0000H
F0467H RMPTR12H – √
F0468H CAN receive buffer register 12CL
Note 2
RMDF012L RMDF012 R – √ √ 0000H
F0469H RMDF012H – √
F046AH CAN receive buffer register 12CH
Note 2
RMDF112L RMDF112 R – √ √ 0000H
F046BH RMDF112H – √
F046CH CAN receive buffer register 12DL
Note 2
RMDF212L RMDF212 R – √ √ 0000H
F046DH RMDF212H – √
F046EH CAN receive buffer register 12DH
Note 2
RMDF312L RMDF312 R – √ √ 0000H
F046FH RMDF312H – √
F0470H CAN receive buffer register 13AL
Note 2
RMIDL13L RMIDL13 R – √ √ 0000H
F0471H RMIDL13H – √
F0472H CAN receive buffer register 13AH
Note 2
RMIDH13L RMIDH13 R – √ √ 0000H
F0473H RMIDH13H – √
F0474H CAN receive buffer register 13BL
Note 2
RMTS13L RMTS13 R – √ √ 0000H
F0475H RMTS13H – √
F0476H CAN receive buffer register 13BH
Note 2
RMPTR13L RMPTR13 R – √ √ 0000H
F0477H RMPTR13H – √
F0478H CAN receive buffer register 13CL
Note 2
RMDF013L RMDF013 R – √ √ 0000H
F0479H RMDF013H – √
F047AH CAN receive buffer register 13CH
Note 2
RMDF113L RMDF113 R – √ √ 0000H
F047BH RMDF113H – √
F047CH CAN receive buffer register 13DL
Note 2
RMDF213L RMDF213 R – √ √ 0000H
F047DH RMDF213H – √
Notes 1. These registers are allocated to the RAM window 0 for the CAN module (receive rule and CAN RAM test register).
When setting these registers, set the RPAGE bit in the GRWCR register to 0.
2. These registers are allocated to the RAM window 1 for the CAN module (receive buffer, receive FIFO buffer,
transmit/receive FIFO buffer, transmit buffer, and transmit history data). When setting these registers, set the
RPAGE bit in the GRWCR register to 1.
