RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 242

Dec 10, 2015

Figure 4-29. Block Diagram of P54

P54/SSI10/

(TI11)/(TO11)

PORT

PU54

(TO11)

P54

P-ch

PU5

PM5

PM54

CMOS

(Schmitt3)

TTL

PIM5

PIM54

PIM

PITHL5

PITHL54

PITHL

CMOS

(Schmitt1)

PMS

PMS0

Internal bus

Output latch

Alternate function

Selector

P5: Port register 5

PU5: Pull-up resistor option register 5

PM5: Port mode register 5

PIM5: Port input mode register 5

PMS: Port mode select register

PITHL5: Port input threshold control register 5

RD: Read signal

WRxx: Write signal
