RL78/F13, F14 CHAPTER 6 TIMER ARRAY UNIT

R01UH0368EJ0210 Rev.2.10 500

Dec 10, 2015

Figure 6-52. Example of Basic Timing of Operation as Frequency Divider (MDmn0 = 1)

Remark TS00: Bit n of timer channel start register m (TSm)

TE00: Bit n of timer channel enable status register m (TEm)

TI00: TI00 pin input signal

TCR00: Timer count register 00 (TCR00)

TDR00: Timer data register 00 (TDR00)

TO00: TO00 pin output signal

TS00

TE00

TI00

TDR00

TCR00

TO00

INTTM00

0002H

Divided

by 6

0001H

0000H

Divided

by 4
