RL78/F13, F14 CHAPTER 7 TIMER RJ
R01UH0368EJ0210 Rev.2.10 552
Dec 10, 2015
Table 7-4. TRJIO0 I/O Edge and Polarity Switching
Operating Mode Function
Timer mode Not used (I/O port)
Pulse output mode 0: Output is started at high (Initialization level: High)
1: Output is started at low (Initialization level: Low)
Event counter mode 0: Count at rising edge
1: Count at falling edge
Pulse width measurement mode 0: Low-level width is measured
1: High-level width is measured
Pulse period measurement mode 0: Measure from one rising edge to the next rising edge
1: Measure from one falling edge to the next falling edge
Table 7-5. TRJO0 Output Polarity Switching
Operating Mode Function
All modes 0: Output is started at low (Initialization level: Low)
1: Output is started at high (Initialization level: High)
To Next Page
