RL78/F13, F14
CHAPTER 14 COMPARATOR (RL78/F14 Only)
R01UH0368EJ021
0 Rev.2.10
777
Dec 10, 2015
Figure 14-1. Comparator B
lock Diagram
Table 14-2. Compar
ator Pin Configuration
Pin Name
I/O
Function
IVCMP00 to
IVCMP03
Input
Analog voltage input pins
IVREF0
Input
External reference voltage input pin
VCOUT0
Output
Comparator outp
ut pin
808
810
