RL78/F13, F14 CHAPTER 2 PIN FUNCTIONS
R01UH0368EJ0210 Rev.2.10 56
Dec 10, 2015
Table 2-2. List of RL78/F14 Pins Other than Port Pins (2/5)
Pin
Function
I/O Function Pin Count
100-
pin
80-pin 64-pin 48-pin 32-pin 30-pin
KR0 Input Key interrupt input
KR1 Input
KR2 Input
KR3 Input
KR4 Input
KR5 Input
KR6 Input
KR7 Input
ANO0 Output D/A converter output
VCOUT0 Output Comparator output
TI00 Input 16-bit timer 00 input
TI01 Input 16-bit timer 01 input (8-bit mode available)
TI02 Input 16-bit timer 02 input
TI03 Input 16-bit timer 03 input (8-bit mode available)
TI04 Input 16-bit timer 04 input
TI05 Input 16-bit timer 05 input
TI06 Input 16-bit timer 06 input
TI07 Input 16-bit timer 07 input
TI10 Input 16-bit timer 10 input
TI11 Input 16-bit timer 11 input (8-bit mode available)
TI12 Input 16-bit timer 12 input
TI13 Input 16-bit timer 13 input (8-bit mode available)
TI14 Input 16-bit timer 14 input
Note 1
Note 1
Note 1
TI15 Input 16-bit timer 15 input
Note 1
Note 1
Note 1
TI16 Input 16-bit timer 16 input
Note 1
Note 1
Note 1
TI17 Input 16-bit timer 17 input
Note 1
Note 1
Note 1
TO00 Output 16-bit timer 00 output
TO01 Output 16-bit timer 01 output (8-bit mode available)
TO02 Output 16-bit timer 02 output
TO03 Output 16-bit timer 03 output (8-bit mode available)
TO04 Output 16-bit timer 04 output
TO05 Output 16-bit timer 05 output
TO06 Output 16-bit timer 06 output
TO07 Output 16-bit timer 07 output
TO10 Output 16-bit timer 10 output
TO11 Output 16-bit timer 11 output (8-bit mode available)
TO12 Output 16-bit timer 12 output
TO13 Output 16-bit timer 13 output (8-bit mode available)
TO14 Output 16-bit timer 14 output
Note 1
Note 1
Note 1
TO15 Output 16-bit timer 15 output
Note 1
Note 1
Note 1
TO16 Output 16-bit timer 16 output
Note 1
Note 1
Note 1
TO17 Output 16-bit timer 17 output
Note 1
Note 1
Note 1
Note 1. Provided only in Group E products.
