RL78/F13, F14 CHAPTER 2 PIN FUNCTIONS

R01UH0368EJ0210 Rev.2.10 66

Dec 10, 2015

Table 2-4. List of RL78/F13 (LIN incorporated) Pins Other than Port Pins (3/4)

Function

I/O Function Pin Count

80-pin 64-pin 48-pin 32-pin 30-pin 20-pin

SCK10

I/O Clock input/output for CSI10

 

Note 1



Note 1

  

SCK11

I/O Clock input/output for CSI11

 

Note 1



Note 1

  

SI00 Input Serial data input to CSI00      

SI01 Input Serial data input to CSI01      

SI10

Input Serial data input to CSI10

 

Note 1



Note 1

  

SI11

Input Serial data input to CSI11

 

Note 1



Note 1

  

SO00 Output Serial data output from CSI00      

SO01 Output Serial data output from CSI01      

SO10

Output Serial data output from CSI10

 

Note 1



Note 1

  

SO11

Output Serial data output from CSI11

 

Note 1



Note 1

  

SSI00 Input Slave select input to CSI00 (SPI00)      

SSI01 Input Slave select input to CSI01 (SPI01)      

SSI10

Input Slave select input to CSI10 (SPI10)

 

Note 1



Note 1

  

SSI11

Input Slave select input to CSI11 (SPI11)

 

Note 1



Note 1

  

LRXD0 Input Serial data input to LIN      

LTXD0 Output Serial data output from LIN      

INTP0 Input External interrupt input      

INTP1 Input      

INTP2 Input      

INTP3 Input      

INTP4 Input      

INTP5 Input      

INTP6 Input      

INTP7 Input      

INTP8 Input  

Note 1



Note 1

  

INTP9 Input  

Note 1



Note 1

  

INTP10 Input  

Note 1

   

INTP11 Input  

Note 1

   

PCLBUZ0 Output Clock output/buzzer output 0      

RESOUT Output Reset output      

STOPST Output STOP status output      

SNZOUT0 Output SNOOZE status output      

SNZOUT1 Output      

SNZOUT2 Output      

SNZOUT3 Output      

SNZOUT4 Output      

SNZOUT5 Output      

SNZOUT6 Output      

SNZOUT7 Output      

RTC1HZ Output Real-time clock correction clock (1 Hz) output      

Note 1. Provided only in the products with 96 Kbytes or 128 Kbytes of ROM.
