Electrical Components
SM 1 D414
Replacement
and
Adjustment
1. REPLACEMENT AND ADJUSTMENT
1.1 ELECTRICAL COMPONENTS
1.1.1 PAPER SENSOR
1. Open the right door of the machine.
2. Remove the front right cover [A] ( x 1).
3. 1-bin-tray [B] ( x 2; M3 x 16)
