Ricoh D025 User Manual

Paper Feed
D023/D025 4-130 SM
4.12.12 FUSING EXIT, PAPER OVERFLOW, JUNCTION PAPER
JAM AND PAPER EXIT SENSOR
1. Paper exit unit (p.4-111 "Paper Exit Unit")
2. Fusing exit sensor bracket [A] ( x 1,  x 1)
3. Remove the fusing exit sensor from the fusing exit sensor bracket ( x 1).
4. Paper overflow sensor [A] ( x 1, hook)

Ricoh D025 Specifications

General

Brand	Ricoh
Model	D025
Category	All in One Printer
Language	English
