Paper Feed
SM 4-1
19
D023/D025
Repla
cement
&
Adjustment
4.12.4
VERTIC
AL TRANSPORT, PAPER OVERFLOW AND
PAPER END SENSOR
1.
Rear cover (
p.4-15 "Rear Cover")
2.
Right rear cover (
p.4-15 "Right Rear Cover")
3.
Paper feed unit (
p.4-102 "Paper Feed Unit")
4.
Paper overflow sensor [A]
5.
Paper end feeler [B] and paper end sensor [C] (hook,
x 1 each)
6.
V
ertical transport sensor bracket [D] (
x 1,
=
x 1)
7.
V
ertical transport sensor [E] (
x 1, hook)
