SC Tables
D023/D025 3-2 SM Appendix
D
The machine operation is
disabled. You can reset the
machine by turning the
operation switch or main switch
off and on. If the error occurs
again, the same SC code is
displayed.
Turn the operation switch or main
power switch off and on.
After you turn the main power switch off, wait for one second or more before you turn the
main power switch on ( SC 672). All SCs are logged. The print log data (SP5-990-004) in
SP mode can check the latest 10 SC codes detected and total counters when the SC code
is detected.
If the problem concerns electrical circuit boards, first disconnect then reconnect
the connectors before you replace the PCBs.
If the problem concerns a motor lock, first check the mechanical load before you
replace motors or sensors.
SC Code Classification
The table shows the classification of the SC codes:
Class 1 Section SC Code Detailed section
100 - Scanner
1XX Scanning
190 - Unique for a specific model
200 - Polygon motor
220 - Synchronization control
230 - FGATE signal related
240 - LD control
280 - Unique for a specific model
2XX Laser exposure
290 - Shutter
