Ricoh D025 - Fusing Gear and One-Way Clutch; Heating Roller Bearing and Insulating Bushing

Fusing
SM 4-111 D023/D025
Replacement
&
Adjustment
4.11.10 FUSING GEAR AND ONE-WAY CLUTCH
1. Fusing unit ( p.4-87)
2. Fusing upper cover (p.4-88 "Pressure Roller Lamp")
3. Rear side stay (p.4-90 "Fusing Lamp")
4. Release the idle gear [A]
5. Release the One-way clutch gear [B] (C-ring x 1)
4.11.11 HEATING ROLLER BEARING AND INSULATING
BUSHING
1. Fusing unit (p.4-87 "Fusing Unit")
2. Fusing upper cover (p.4-88 "Pressure Roller Lamp")
3. Rear side stay (p.4-90 "Fusing Lamp")
4. Front side stay (p.4-88 "Pressure Roller Lamp")
5. Fusing lamp (p.4-90 "Fusing Lamp")
6. Remove the rear and front heating roller bearings [A] and insulating bushings [B].
