SC Tables
D023/D025 3-62 SM Appendix
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Paper position sensor slide motor error
The paper position sensor moves but is not detected at the home
position within the specified time. The 1st detection failure issues a jam
error, and the 2nd failure issues this SC code.
Motor harness disconnected, loose, defective
Defective motor
765 B
1. Check the connections to the paper position sensor slide motor.
2. Defective paper position sensor slide motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Paper position sensor slide motor error
The paper position sensor moves but is not detected at the home
position within the specified time. The 1st detection failure issues a jam
error, and the 2nd failure issues this SC code.
Motor harness disconnected, loose, defective
Defective motor
766 B
1. Check the connections to the paper position sensor slide motor.
2. Defective paper position sensor slide motor.
