Jam Detection
SM Appendix 6-5 D023/D025
Appendix
Jam
Detection
Jam Code
SP
Display Description
LCD
Display
7504 68 - - -
7504 100
Finisher Entrance
(B408)
Paper does not reach to the entrance
sensor or stay at the entrance sensor.
R1-R2
7504 101
Finisher Shift Tray Exit
(B408)
Paper does not reach to the lower tray
exit sensor or stay at the lower tray exit
sensor.
R1-R2
7504 102 Finisher Staple (B408)
Paper does not reach to the staple tray
entrance sensor or stay at the staple
tray entrance sensor.
R3-R5
7504 103 Finisher Exit (B408)
Lower tray exit sensor does not detect
paper after the stack feed-out belt has
fed paper.
Lower tray exit sensor still detects paper
after the stack feed-out belt has
returned to the home position.
R3-R5
7504 104 - - -
7504 105
Finisher Tray Lift
Motor (B408)
Stack height sensor does not detect
paper after the lower tray has lifted up.
Stack height sensor still detects paper
after the lower tray has lifted down.
R1-R2
