System Service Mode
D023/D025 8-118 SM Appendix
[Special 1: Paper Size Correction]
2761
Adjusts the size correction coefficient for the paper transfer roller current for
each paper size. SP2753 and SP2757 are multiplied by these SP values.
Plain: 154 mm/sec, Fine: 77 mm/sec
001
Paper Transfer: Plain: 1st Side:
S1
*ENG
002
Paper Transfer: Plain: 2nd
Side: S1
*ENG
[100 to 600 / 100 / 5%/step]
S1 size ≥ 297 mm (Paper width)
005
Paper Transfer: Plain: 1st Side:
S2
*ENG
006
Paper Transfer: Plain: 2nd
Side: S2
*ENG
[100 to 600 / 120 / 5%/step]
297 mm ≥ S2 size ≥ 275 mm
(Paper width)
009
Paper Transfer: Plain: 1st Side:
S3
*ENG
010
Paper Transfer: Plain: 2nd
Side: S3
*ENG
[100 to 600 / 140 / 5%/step]
275 mm ≥ S3 size ≥ 210 mm
(Paper width)
013
Paper Transfer: Plain: 1st Side:
S4
*ENG
[100 to 600 / 160 / 5%/step]
210 mm ≥ S4 size ≥ 148 mm
(Paper width)
014
Paper Transfer: Plain: 2nd
Side: S4
*ENG
[100 to 600 / 160 / 5%/step]
210 mm ≥ S4 size ≥ 148 mm
(Paper width)
017
Paper Transfer: Plain: 1st Side:
S5
*ENG
[100 to 600 / 180 / 5%/step]
148 mm ≥ S5 size (Paper width)
018
Paper Transfer: Plain: 2nd
Side: S5
*ENG
[100 to 600 / 180 / 5%/step]
148 mm ≥ S5 size (Paper width)
