System Service Mode
SM Appendix 8-123 D023/D025
Appendix
SP Mode
Tables
[Special 2: Bias: FC]
2807
Adjusts the current for the paper transfer roller for special paper 2 in full color
mode.
Plain: 154 mm/sec, Fine: 77 mm/sec
001 Paper Transfer: Plain: 1st Side *ENG
[0 to 200 / 30 / 1 –μA /step]
002 Paper Transfer: Plain: 2nd Side *ENG
[0 to 200 / 33 / 1 –μA /step]
003 Separation DC: Plain: 1st Side *ENG
[0 to 200 / 15 / 1 –μA /step]
[Special 2: Paper Size Correction]
2811
Adjusts the size correction coefficient for the paper transfer roller current for
each paper size. SP2803 and SP2807 are multiplied by these SP values.
Plain: 154 mm/sec, Fine: 77 mm/sec
001
Paper Transfer: Plain: 1st Side:
S1
*ENG
002
Paper Transfer: Plain: 2nd Side:
S1
*ENG
[100 to 600 / 100 / 5%/step]
S1 size ≥ 297 mm (Paper
width)
005
Paper Transfer: Plain: 1st Side:
S2
*ENG
[100 to 600 / 120 / 5%/step]
297 mm ≥ S2 size ≥ 275 mm
(Paper width)
006
Paper Transfer: Plain: 2nd Side:
S2
*ENG
[100 to 600 / 120 / 5%/step]
297 mm ≥ S2 size ≥ 275 mm
(Paper width)
009
Paper Transfer: Plain: 1st Side:
S3
*ENG
[100 to 600 / 140 / 5%/step]
275 mm ≥ S3 size ≥ 210 mm
(Paper width)
