Ricoh D025 - Page 751

System Service Mode
SM Appendix 8-155 D023/D025
Appendix
SP Mode
Tables
005-008
Displays or adjusts the Vtcnt value for each color at developer initialization.
DFU
005 Initial: Bk *ENG
006 Initial: M *ENG
007 Initial: C *ENG
008 Initial: Y *ENG
[2 to 5 / 3.86 / 0.01 V/step]
[Vtref: Display/Set]
3222
Displays or adjusts the current Vtref value for each color.
001 Current: Bk *ENG
002 Current: M *ENG
003 Current: C *ENG
004 Current: Y *ENG
[0 to 5.5 / 3 / 0.01 V/step]
005-008
Displays or adjusts the Vtref value for each color at developer initialization.
DFU
005 Initial: Bk *ENG
006 Initial: M *ENG
007 Initial: C *ENG
008 Initial: Y *ENG
[0 to 5.5 / 3 / 0.01 V/step]
