System Service Mode
SM Appendix 8-157 D023/D025
Appendix
SP Mode
Tables
012 Upper Sensitivity *ENG
Adjusts the upper limit of the TD sensor
sensitivity.
[0.2 to 0.5 / 0.44 / 0.001 V/wt% /step]
013 Lower Sensitivity *ENG
Adjusts the lower limit of the TD sensor
sensitivity.
[0.2 to 0.5 / 0.209 / 0.001 V/wt% /step]
014
Toner Density Between H
and M
*ENG
[1 to 10 / 3.5 / 0.1 wt%/step]
015
Toner Density Between M
and L
*ENG
[1 to 10 / 3.5 / 0.1 wt%/step]
[Vtref Correction: Pixel] DFU
3224
Adjusts the coefficient of Vtref correction for each coverage and color.
001 Low Coverage Coefficient: Bk *ENG
002 Low Coverage Coefficient: M *ENG
003 Low Coverage Coefficient: C *ENG
004 Low Coverage Coefficient: Y *ENG
[0 to 5 / 1 / 0.1 /step]
005 High Coverage Coefficient: Bk *ENG
[0 to 5 / 1 / 0.01 V/step]
006 High Coverage Coefficient: M *ENG
007 High Coverage Coefficient: C *ENG
008 High Coverage Coefficient: Y *ENG
[0 to 5 / 0.5 / 0.01 V/step]
009 Low Coverage: Threshold *ENG
Adjusts the threshold of the
low coverage.
[0 to 20 / 3 / 0.1 %/step]
