System Service Mode
D023/D025 8-164 SM Appendix
005-008
Displays the average coverage of each color for the Vtref correction.
"Average S" is defined when the number of developed pages does not reach
the number specified with SP3251-017.
005 Average S: Bk *ENG
006 Average S: M *ENG
007 Average S: C *ENG
008 Average S: Y *ENG
[0 to 100 / 5 / 0.01 %/step]
009-012
Displays the average coverage of each color for the Vtref correction.
"Average M" is defined when the number of developed pages does not reach
the number specified with SP3251-018.
009 Average M: Bk *ENG
010 Average M: M *ENG
011 Average M: C *ENG
012 Average M: Y *ENG
[0 to 100 / 5 / 0.01 %/step]
013-016
Displays the average coverage of each color for the Vtref correction.
"Average L" is defined when the number of developed pages does not reach
the number specified with SP3-251-019.
013 Average L: Bk *ENG
014 Average L: M *ENG
015 Average L: C *ENG
016 Average L: Y *ENG
[0 to 100 / 5 / 0.01 %/step]
