System Service Mode
SM Appendix 8-203 D023/D025
Appendix
SP Mode
Tables
4570 [Scanner Application: Color: Text-Photo] DFU
4571 [Scanner Application: Color: Glossy Photo] DFU
4572 [Scanner Application: AutoColor] DFU
MTF: 0 (Off), 1-15 (Strong) *ENG
[0 to 15 / 8 / 1 /step]
0: MTF Off
-005
Sets the MTF level (Modulation Transfer Function) designed to improve image
contrast. Set higher for stronger effect, lower for weaker effect.
Smoothing: 0 (x1), 1-7 (Strong) *ENG
[0 to 7 / 4 / 1 /step]
-006
Use to remove "jaggies" if they appear. Set higher for smoother images.
Brightness: 1–255 *ENG
[1 to 255 / 128 / 1 /step]
-007
Set higher for darker, set lower for lighter.
Contrast: 1–255 *ENG
[1 to 255 / 128 / 1 /step]
-008
Set higher for more contrast, set lower for less contrast.
Independent Dot Erase (0), 1-7 (Strong) *ENG
[0 to 7 / 0 / 1 /step]
-009
Sets the erasure level of Irregular Dots. Set higher for stronger effect, lower for
weaker effect.
0: Not activated
