System Service Mode
SM Appendix 8-247 D023/D025
Appendix
SP Mode
Tables
[Free Run]
5802
Performs a free run on the copier engine.
The machine starts free run in the same condition as the sequence
of A4/LT, A3 or A4 SEF printing from the 1st or 2nd tray. Therefore,
the correct paper should be loaded in the 1st tray or 2nd tray, but
paper is not fed.
The main switch has to be turned off and on after using the free run
mode for a test.
001 TRAY1: A4LEF: FC -
002 TRAY2: A3: FC -
003 TRAY2: A4SEF: FC -
-
5803 [Input Check]
- See "Input Check Table" in this section.
5804 [Output Check]
- See "Output Check Table" in this section.
5805 [Anti-Condensation Heater]
002 0:OFF / 1:ON *ENG
[0 or 1 / 0 / -]
[SC Reset]
5810
Resets a type A service call condition.
Turn the main switch off and on after resetting the SC code.
001 Fusing SC Reset - -
