System Service Mode
D023/D025 8-318 SM Appendix
007 Page: Development Unit: M
008 Page: Development Unit: C
009 Page: Development Unit: Y
010 Page: Developer: Bk
011 Page: Developer: M
012 Page: Developer: C
013 Page: Developer: Y
014 Page: Image Transfer
015 Page: Cleaning Unit
016 Page: Fusing Unit
017 Page: Paper Transfer Unit
018 Page: Toner Collection Bottle
Displays the number of revolutions of motors or clutches for each current
maintenance unit.
[ 0 to 9999999 / 0 / 1 revolution/step ]
When a unit is replaced, the machine automatically detects that the new unit
is installed. Then, the current PM counter value is automatically moved to the
PM Counter - Previous (SP7-906-11 to 20) and is reset to “0”. The total
number of revolutions made with the last unit replaced can be checked with
SP7-906-11 to 20.
031 Rotation: PCU: Bk
032 Rotation: PCU: M
033 Rotation: PCU: C
034 Rotation: PCU: Y
*ENG
[0 to 999999999 / - / 1
mm/step ]
