Ricoh Interactive Whiteboard Controller Type 2 User Manual

No. Terminal Devices Connection method
7
DisplayPort Input
• Computer
• Tablet
• Document camera
You cannot display copyright-
protected content such as DVD
and Blu-ray discs.
See page 99 "Connecting a
Computer or Tablet to the
Machine".
• To display a copyright-
protected material, connect
to the HDMI Input 1/2 of the
main unit. For the input/
output terminals of the main
unit and other parts of the
machine, see "Read This
First" of RICOH Interactive
Whiteboard D8600.
8
VGA Input
• Computer
• Tablet
• Document camera
See page 99 "Connecting a
Computer or Tablet to the
Machine".
• For details about the input signals that are supported, see page 316 "List of Video Input Signals
Supported by the Machine".
• The audio signals of the HDMI Input and DisplayPort Input are output to the audio output terminals.
• When more than one device is connected to the input terminals, priority is given to the terminals in
the order of HDMI Input, DisplayPort Input, and VGA Input.
• To display an externally input still or video image on the machine in cases other than for citation,
the material must be created by yourself and you must own the copyright, or you must be granted
permission to use the material from the rightful owner of the copyright.
• A delay may occur when an image is displayed that is input from the HDMI, DisplayPort, or VGA
input terminal due to various composite processing methods such as overlaying entries.
3. Connecting Devices
98
